Refit 2020 – NCA Refit
Project Manager for NCA shipyard to manage refit activities.
Shipyard Heesen Shipyards BV Build year 1994 LOA 42,10 m Beam 7,88 m Draft 2,17 m Displ 192 tonnes (Light Ship) Gross Tonnage 339 GT Accomodation 12 guests (1 Master, 2 Double, 2 Twin) + 8 crew Engines 2x MTU 8V 4000 M70 Diesel 1556 hp Speed 17 Knots Construction Aluminium Class ABS
Refit 2020 – NCA Refit
Project Manager for NCA shipyard to manage refit activities.
Shipyard Feadship Build year 2007 LOA 67,00 m Beam 11,80 m Draft 3,6 m Gross Tonnage 1.549 GT Accomodation 17 guests (4 × double, 2 × twin, 1 × single, 4 × additional berths) + 18 crew Engines 2x Caterpillar 3516 BDI 2.682 hp Max Speed 16 Knots Cruising Speed 13 Knots Range 5.100 nm Construction Steel Class Lloyd’s
Magnum 53’ Maltese – Elisabet JR
Refit 2018-2020
Total refitting with new design and engineering.
Project management, purchases management and shipyard activities direction.
Shipyard Magnum Marine Corp Model Magnum 53’ Maltese Build year 1979 Total refit 2020 LOA 16,15 m Beam 4,80 m Draft 1,10 m Displ approx. 28 tons dry , 33 tons full load Accomodation 2 guests (master cabin) + 2 crew cabins Engines 2x MAN V8 1300 hp Propulsion 2x ASD 12L Arneson Surface Drives + Rolla Surface Propellers Max Speed 45 knots Construction GRP Class RINA Cat B
Refit 2018-2019 – Perini Navi
New anchor system: proposal design and workshop drawings for production.
Technical consulting.
Shipyard Magnum Marine Corp Model Magnum 60’
Build year 2004 Total refit 2020 to Perini Navi LOA 18,28 m Beam 4,84 m Draft 1,04 m Displ approx. 28 tons Accomodation 4 guests (1 double + 1 twin) + crew cabin Engines 2x MTU 16v2000 1800hp Propulsion 2x ASD14 Arneson Surface Drives + Rolla Surface Propellers Max Speed 55 knots Construction GRP Class RINA
Refit 2011 – 2019 – collaboration with Matrix Marine sarl
Project Manager for refit activities and works direction in Genoa (Amico&Co), Barcelona(MB92) and Miami FL.(Raybovich)
Shipyard CRN Spa Build year 2010 LOA 72.00 m Beam 13.50 m Draft 3.50 m Gross Tonnage 2.043 GT Accomodation 12 guests (1 master, 5 doubles) + 28 crew Engines 2x CAT 3516B-CHD Diesel 2682 HP Speed Max. 16.5 knots Cruising Speed 15 Knots Range 6.000 N/M Fuel capacity 250.000 l Water capacity 40.000 L Construction Steel Class Lloyd’s
Nereids Yachts 50 m – M.Y. Azteca 2 EX M.Y. THETIS
Refit 2017 – 2018 – collaboration with Matrix Marine sarl
Project Manager and works direction for refit activities in San Diego – USA.
Shipyard Nereids Yachts Build year 2005 LOA 49.70 m Beam 9.80 m Draft 2.80 m Gross Tonnage 497 GT Accomodation 12 guests (1 master, 5 doubles) + 12 crew Engines 2x CAT 3512 B Diesel 2250 hp Max Speed 17 knots Cruising Speed 14 Knots Range 5.400 N/M Fuel capacity 110.000 l Water capacity 17.000 l Construction Steel + Aluminium Class Bureau Veritas
Advanced Yachts – A66/03 – Under construction
New build 2018-2020 – project Nauta Design
Technical support with engineering and production drawings.
Shipyard Advanced Yachts Model A66-03 Build year in construction LOA 20.46 m Beam 5.40 m Draft 3.20 m Displ 24.000 Kg Ballast 8.600 Kg Sail area 225 m2 Mast height 26 m Accomodation 6/8 guests + 2/4 crew Fuel tank 1.560 l Water tank 900 l Engine Yanmar 4LHA DTP 200 HP Construction GRP/Carbon fiber
Advanced Yachts – A80/02 – JIKAN
New build 2017-2018 – project Nauta Design
Technical support with engineering and production drawings.
Shipyard Advanced Yachts Model A80-02 Build year 2018 LOA 23.98 m Beam 6.20 m Draft 3.50 m Displ 39.700 Kg Ballast 11.780 Kg Sail area 326 m2 Mast height 30.20 m Accomodation 6 guests + 4 crew Fuel tank 2.000 l Water tank 1.300 l Engine Yanmar 4LHA DTP 230 HP Construction Carbon fiber
Refit 2017
Project management and shipyard works direction for Matrix Marine sarl.
Shipyard Magnum Marine Corp Model Magnum 60’ Build year 2007 Refit year 2017 LOA 18,28 m Beam 4,84 m Draft 1,04 m Displ approx. 28 tons Accomodation 4 guests (1 double +1 twin) + crew cabin Engines 2x CAT 1420 hp Propulsion 2x ASD14L Arneson Surface Drives + Rolla Surface Propellers Max Speed 52 knots Contruction Composite Class RINA
Refit 2016-2017 – collaboration with Matrix Marine sarl
New interior and exterior design.
Project management and works direction.
Shipyard Magnum Marine Corp Model Magnum 53’ Maltese Build year 1982 Refit year 2016/2017 LOA 16,15 m Beam 4,80 m Displ approx. 26 tons Accomodation 4 guests (1 double + 1 twin) + 1 crew cabin Engines 2x CAT C18 ACERT 1000 hp Propulsion 2x ASD12 Arneson Surface Drives + Rolla Surface Propellers Max Speed 44 knots Construction Composite Class RINA
Refit 2016-2017 –CNC (Carasco) –collaboration with Santa Marina Yachts
New interior and exterior design.
Project management and works direction.
Shipyard Magnum Marine Corp Model Magnum 44’ Build year 1999 Refit year 2016/2017 LOA 13,41 m Beam 3,73 m Draft 1,06 m Displ approx. 15 tons Accomodation 2 guests (master cabin) Engines 2x CAT diesel 800 hp Propulsion 2x ASD11 Arneson Surface Drives + Rolla Surface Propellers Max Speed 44 knots Construction Composite Class RINA
New construction 2016-2020 – nr.5 construction
Total project and design.
Technical Project, structural drawings, certification
Shipyard Mussini srl Model Paraggina 10 Build year2013-2020 LOA 9,98 m Beam 3,50 m Draft 0,98 m Displ approx. 6,2 tons Accomodation 2 guests (1 double+bathroom) Engines 2x YANMAR 220 Hp eb turbodiesel Max Speed 24 knots Construction GRP/Wood Class RINA Cat B (10 pers.) Cat C (15 pers.)
Refit 2016-2017 –Porto Carolina –collaboration with Santa Marina Yachts
Project management and shipyard works direction.
Shipyard Magnum Marine Corp Model Magnum 53 Sport Build year 1990 Refit year 2016/2017 LOA 16.15 m Beam 4.80 m Displ approx. 26 tons Accomodation 4 guests (1 double + 1 twin) + 1 crew cabin Engines 2x MAN 1050 hp Propulsion 2x ASD12 (Arneson) + Rolla Surface Propellers Max Speed 42 knots Construction GRP Class RINA
Viking 82’ Enclosed bridge – It’s Time
New 2016 – Porto Lotti
Project Manager for owner to manage bimini custom activities.
Shipyard Viking Yachts Model Viking 82’EB Build year 2016 LOA 83 ft 5 in Beam 22 ft 4 in Draft 5 ft 6 in Dry Weight 162250 lbs Accomodation 8 guests (1× double, 3 × twin) Engines 2x CAT C32 ACERT 1925 hp Max Speed 36 Knots Tanks Fresh Water Tanks (486 Gallons);Fuel Tanks (3600 Gallons);Holding Tanks (296 Gallons) Construction GRP Class RINA
Patrol Boat 48’ – Intercepteur 16m
New 2016 – WMagic yachts Biserta
Design and rendering for shipyard
Shipyard WMagic Model Patrol boat 48’ Build year 2016 LOA 13,5 m Beam 4,4 m Shipyard WMagic Model Interceteur Build year 2016 LOA 16 m Beam 3 m
Riva Corsaro 20m –Rima
Refit 2015-2016 – Italy – collaboration with Matrix Marine sarl
Design and Project Manager for Matrix Marine sarl to manage refit activities.
Shipyard Riva Model Corsaro 20m Build year 1992 Refit year 2015-2016 LOA 18,31 m Beam 5,30 m Draft 1,65 m Gross Tonnage 47,45GT Accomodation 5 guests (2× double,1 × single) + 1 crew cabins Engines 2x Mtu 12v183TE 1000 hp Max Speed 32 Knots Tanks Fresh Water Tanks: 1 (800 Liters); Fuel Tanks: 1 (4150 Liters) Construction GRP Class RINA
Refit 2015-2016 – collaboration with Matrix Marine sarl
Project management and shipyard works direction.
Shipyard Magnum Marine Corp Model Magnum 60’ Build year 2009 Refit year 2016 LOA 18,28 m Beam 4,84 m Draft 1,04 m Displ approx. 28 tons Accomodation 4 guests (1 double +1 twin) + crew cabin Engines 2x CAT C32 1670 hp Propulsion 2x ASD14L Arneson Surface Drives + Rolla Surface Propellers Max Speed 52 knots Construction Composite Class RINA
Refit 2015-2016 – collaboration with Matrix Marine sarl
Project management and shipyard works direction.
Shipyard Magnum Marine Corp Model Magnum 63’ Build year2009 Refit year 2015/2016 LOA 18,28 m Beam 4,84 m Draft 1,04 m Displ approx. 28 tons Accomodation 4 guests (1 double +1 twin) + crew cabin Engines 2x CAT 3412E DITA 1420 hp Propulsion 2x ASD14 Arneson Surface Drives + Rolla Surface Propellers Max Speed 42 knots Construction Composite Class RINA
Riva Athena 115’ – M.Y. Babousha
Refit 2015 - 2016 – WMagic yachts Biserta
Project Manager for owner to manage refit activities.
Shipyard Riva Model Athena 115’ Build year 2007 LOA 35,40 m Beam 7,08 m Draft 2,05 m Displ. 162 tons Accomodation 8 guests (2× double, 2 × twin, 1 × single) + 5 crew in 3 cabins Engines 2x Mtu 4000 12v M90 2700 hp Max Speed 27 Knots Cruising Speed 23 Knots Tanks Fresh Water Tanks: 1 (4000 Liters); Fuel Tanks: 1 (23450 Liters); Holding Tanks: 1 (1700 Liters) Construction GRP Class RINA
Intrepid 400 cc – Maya – t.t. M.Y. Azteca
Refit 2015 – collaboration with Matrix Marine sarl
Shipyard Intrepid Model 400 center console Build year 2010 Refit year 2015 LOA 40 ft 0 in Beam 11 ft 1 in
Engines Total Power 1050 HP, Yamaha Engine - 300 HP V-6 Triple Four Stroke Cruising Speed 45 mph @ 4000 RPM Max Speed 62 mph Tanks Fresh Water Tanks: 1 Plastic (40 Gallons) Fuel Tanks: 2 Aluminum (400 Gallons)
Holding Tanks: 1 Plastic (20 Gallons)
Mussini Paraggina 10 – Serial construction
New construction 2013-2020 – nr.7 construction
Design arch. E. Miola
Technical Project, structural drawings, certification
Shipyard Mussini srl Model Paraggina 10 Build year2013-2020 LOA 9,98 m Beam 3,50 m Draft 0,98 m Displ approx. 6,2 tons Accomodation 2 guests (1 double+bathroom) Engines 2x YANMAR 220 Hp eb turbodiesel Max Speed 22 knots Construction GRP/Wood Class RINA Cat B
Riva Black Corsair 60’ – Zoro
Refit 2013-2014 – Dubai – collaboration with Matrix Marine sarl
Design, project management and shipyard works direction for refit activities.
Shipyard Riva Model Black Corsair 60’ Build year 1989 Refit year 2013-2014 LOA 18,71 m Beam 5,35 m Draft 0,93 m Displ approx. 23 tons Accomodation 4 guests (1× double,1 × twin) + 1 crew cabins Engines 2x Mtu 10v2000 M94 1620 hp Max Speed 42 Knots Cruising Speed 32 Knots Tanks Fresh Water Tanks: 1 (800 Liters); Fuel Tanks: 1 (2500 Liters); Holding Tanks: 1 (300 Liters) Construction GRP Class RINA
Amtec Turkey 48m – M.Y. Out
Refit 2013 – collaboration with Coop Steel Works
Design and rendering for sundack forniture and upper salon
Shipyard Amtec Turkey Build year 2002 LOA 48.00 m Beam 8,3 m Draft 3.6 m Gross Tonnage 396GT Accomodation 12 guests+ 10 crew Engines 2x Caterpillar 3508 1000 hp Max Speed 13 Knots Cruising Speed 12.5 Knots Construction Steel Class Bureau Veritas
New 2012 – Lavagna –project Della Rosa and Nauta Design
Technical support with renders and 3d drawings for STA company (Studio Tecnico Averame).
Shipyard Castagnola Build year 2012 LOA 39 m Beam 8,20 m Draft 3,7 m Hull Material wood Accomodation 10 guests (3 double + 2 twin) + 3 crew cabin Engines 2x CAT 450 hp Max Speed 12 Knots Cruising Speed 9 Knots Construction wood Class RINA
Alloy Yachts 28m – S.Y. Irelanda
Refit 2012 – Lavagna
Design, project management and shipyard works direction for refit activities.
Shipyard Alloy Yachts Build year 1998 LOA 31,94 m Beam 7,15 m Draft 3,5 m Gross Tonnage 130 GT Accomodation 6 guests + 3 crew Engines 1x Lugger L6140A 553 hp Max Speed 12,5 Knots Cruising Speed 10 Knots Range 2.500 nm Construction Alluminium Class GL
Otam 58’ HT – Millenium 58’ HT
New 2012 – Genova / Varazze – collaboration with Matrix Marine sarl
Survay for owner garancy works.
Shipyard Otam Model Millenium 58’ HT Build year 2012 LOA 18,70 m/16,75m Beam 4,68 m Draft 1,29 m Displ approx. 29,5 tons half load Accomodation 6 guests (1 double +1 twin)+ 1 crew cabin Engines 2 x CAT C32 1670 hp Propulsion 2x ASD14L Arneson Surface Drives + Rolla Surface Propellers Max Speed 55 knots Construction Composite/GRP Class RINA Cat B
Otam 58’ open– Millenium 58’ open
New 2012 – Genova / Varazze – collaboration with Matrix Marine sarl
Survay for owner garancy works.
Shipyard Otam Model Millenium 58’ open Build year 2012 LOA 18,70 m/16,75m Beam 4,68 m Draft 1,29 m Displ approx. 29,5 tons half load Accomodation 6 guests (1 double +1 twin) +1 crew cabin Engines 2 x CAT C32 1670 hp Propulsion 2x ASD14L Arneson Surface Drives + Rolla Surface Propellers Max Speed 55 knots Construction Composite/GRP Class RINA Cat B
Otam 80’ Record – Egoiste EX BLACK BULLET
Refit 2011 – Varazze –Italy
Project and design new custom bimini.
Shipyard Otam Model 80’ Record Build year 2005 Refit year 2014 LOA 25.50 m Beam 6,05 m Draft 1,30 m Displ approx. 48 tons full load, 39 tons dry Accomodation 6 guests (1 double +2 twin) +2 crew cabin Engines 4 x CAT C32 1670 hp Propulsion 4x Trimax system Max Speed 54 knots Construction Composite/GRP Class RINA
Magnum 53’ Sport – GForce – Under construction
Project 2011 – Dubai/Italy – collaboration with Matrix Marine sarl
Design and total Project.
Shipyard Magnum Marine Corp Model Magnum 53 Sport Build year 1986 Refit year in stand by LOA 16,15 m Beam 4,80 m Displ approx. 26 tons Accomodation 4 guests (1 double + 1 twin/convertible dinette) + 1 crew cabin Construction GRP
Refit 2010-2014 – Mondomarine – collaboration with Matrix Marine sarl
Design, project management and shipyard works direction for refit activities.
Shipyard Humber St. Andrews Engeenering Company Build year 1962 Refit year 2010-2014 LOA 27,05 m Beam 7,01 m Draft 3.9 m Gross Tonnage 98GT Displ approx. 232 tons full load, 195 tons dry Accomodation 6 guests (1 × double, 2 × twins) + 3 crew Engines 2 x EVS6 MGR Lister Blackstone 396 hp Max Speed 11,5 Knots Cruising Speed 9 Knots Range 2.400 nm Construction Steel Class Lloyd’s expired
Refit 2010-2014 – Dubai/Italy – collaboration with Matrix Marine sarl
Total refitting with new design and engineering.
Project management, purchases management and shipyard activities direction.
Shipyard Magnum Marine Corp Model Magnum 70’ Build year 1991 Refit year 2014 LOA 21.15 m Beam 5,13 m Draft 1,30 m Displ approx. 48 tons full load, 39 tons dry Accomodation 6 guests (1 double +1 twin + 2 single) +1 crew cabin Engines 2 x MTU 16V2000M93 2400 hp Propulsion 2x ASD15L Arneson Surface Drives + Rolla Surface Propellers Max Speed 54 knots Construction Composite/Kevlar Class RINA
Leopard 24m – Sadelan 2
Refit 2009-2010 – Montecarlo – collaboration with Ulisse Yacht
Project and design new custom bimini.
Shipyard Cantieri Arno Model Leopard 24m Refit year 2009-2010 LOA 23,96 m Beam 6 m Draft 1,3 m Displ approx. 48,7 tons Accomodation 6 guests (2 double + 1 twin) + 3 crew Engines 2x MTU 12V 2000 M93 1500 hp Propulsion 2x ASD14L Arneson Surface Drives + Rolla Surface Propellers Max Speed 36 knots Cruising Speed 32 Knots Construction GRP Class RINA
Camper & Nicholson 45,54 m – M.Y. Tanit
Refit 2009 – Amico&Co
Design and system drawings for STA company (Studio Tecnico Averame).
Shipyard Camper & Nicholson Build year 1967 Refit year 2009 LOA 45,54 m Beam 7,83 m Draft 3.9 m Displ approx. 390 tons Accomodation 12 guests +18 crew Engines 2 x Man G6V23.5/33 diesel 600 hp Max Speed 14,5 Knots Cruising Speed 12,5 Knots Range 2.500 nm Construction Steel Class Lloyd’s
Refit 2008 –Italy
Project and shipyard works direction for bimini custom and repaint.
Shipyard Magnum Marine Corp Model Magnum 70’ Build year 1990 Refit year 2008 LOA 21.15 m Beam 5,13 m Draft 1,30 m Displ approx. 42 tons Accomodation 4 guests (1 double +1 twin) + 2 crew cabin Engines 2 x MTU 1650 hp Propulsion 2x ASD14 Arneson Surface Drives + Rolla Surface Propellers Max Speed 37 knots Construction Composite/Kevlar Class RINA
Refit 2007 –CNL (Carasco) – collaboration with Santa Marina Yachts
Project management and shipyard works direction.
Shipyard Magnum Marine Corp Model Magnum 53 Sport Build year 1990 Refit year 2007 LOA 16.15 m Beam 4.80 m Displ approx. 26 tons Accomodation 4 guests (1 double + 1 twin) + 1 crew cabin Engines 2x GM 12V 92 1080 hp Propulsion 2x ASD12 (Arneson) + Rolla Surface Propellers Max Speed 48 knots Construction GRP Class RINA
Princess V50 – M.4
Refit 2007-2008 – Genova –Italy
Project and design for hard top
Shipyard Princess Model V50’ Refit year 2007-2008 LOA 15.49 m Beam 4.27 m Draft 1,09 m Accomodation 4 guests Engines 2 x Volvo Penta D12 700 hp Max Speed 35 knots Cruising Speed 28 Knots Construction GRP Class RINA
Refit 2006-2007 – ATN Yacht interiors – collaboration with Santa Marina Yachts
Design, project management and shipyard works direction for refit activities.
Shipyard Magnum Marine Corp Model Magnum 53 Sport Build year 1986 Refit year 2006-2007 LOA 16.15 m Beam 4.80 m Displ approx. 26 tons Accomodation 4 guests (1 double + 1 twin) + 1 crew cabin Engines 2x GM 12V 92 1080 hp Propulsion 2x ASD12 (Arneson) + Rolla Surface Propellers Max Speed 44 knots Construction GRP Class RINA
Cerri 86’ FlyingSport – Seven
New 2006 – Cerri cantieri navali – collaboration with Santa Marina Yachts
Project and design for owner.
Shipyard Cerri cantieri navali Model 86’ FlyingSport Build year 2006 LOA 26,30 m Beam 6,35 m Draft 1,28 m Displ approx. 61 tons Accomodation 6 guests (2 double + 1 twin) + 2 crew cabin Engines 2x MTU 16V2000 2030 hp Propulsion 2x ASD15L Arneson Surface Drives + Rolla Surface Propellers Max Speed 40 knots Cruising Speed 35 Knots Construction GRP Class RINA
New 2005-2006 – ATN Yacht interiors – collaboration with Santa Marina Yachts
Design Lazzarini&Pickering.
Project management and shipyard works direction for owner.
Shipyard Magnum Marine Corp Model Magnum 60’ Build year 2005 LOA 18,28 m Beam 4,84 m Draft 1,04 m Displ approx. 28 tons Accomodation 8 guests (4 sofa/double) + 1 crew cabin Engines 2x CAT C32 1670 hp Propulsion 2x ASD14L Arneson Surface Drives + Rolla Surface Propellers Max Speed 52 knots Construction Composite Class RINA
Off Course 55’ HT – Number1
Project 2005–2006
Shipyard Off Course Model 55’ HT Build year 2005-2006 LOA 15,9 m Beam 4,56 m Displ approx. 24 tons Accomodation 4 guests (2 double) + 1 crew cabin Engines 2x MAN 800 hp Propulsion 2x Top System Surface Drives + Surface Propellers Max Speed 45 knots Construction GRP
New 2004-2005 – ATN Yacht interiors – collaboration with Santa Marina Yachts
Hydraulic bimini drawings and project management .
Shipyard Magnum Marine Corp Model Magnum 60’ Build year 2004 LOA 18,28 m Beam 4,84 m Draft 1,04 m Displ approx. 28 tons Accomodation 4 guests + 1 crew cabin Engines 2x CAT C32 1670 hp Propulsion 2x ASD14L Arneson Surface Drives + Rolla Surface Propellers Max Speed 52 knots Construction Composite Class RINA
F.lli Benetti FB 31,5m – M.Y. Solaria ex M.Y. Scotland Cay
Refit 2004-2005 – Mondomarine
Design and Project Manager for owner to manage refit activities.
Shipyard F.lli Benetti Build year 1972 LOA 31,50 m Beam 6,2 m Draft 2,45 m Displ approx.186 tons full load, Accomodation 10 guests + 6 crew Engines 2x Detroit Diesel 16VA-71N 470 hp Max Speed 14 Knots Cruising Speed 12 Knots Construction Steel/Alluminium for superstructure Class Not in class
